Columbus Futura Disc fork

The fork Columbus Futura Caliper Disc is a fork for road bike of the latest generation.

Of a 100% carbon monohull construction it combines lightness, stiffness and strength.

It will be ideal to equip your road bike or your urban bike to conical steering socket and to disc braking.

Details below.

The fork Columbus Futura is available in several variants :

• Columbus Futura Caliper : For road bikes with conical socket and roller brake
• Columbus Futura Caliper SL : For road bikes with right socket and skate braking
• Columbus Futurea Disc : For road bikes with conical socket and disc brake
• Columbus Futura Gravel : For engravel bike with conical socket, disc brake and large tires
• Columbus Futura Cross : For engravel bike with conical socket, disc brake and very large tires

Detailed specifications of the fork Columbus Futura Disc:

• Material: Toray carbon fiber T700S x HFM
• Pivot dimensions : 1 1/8" - 1 1/2"
• Weight: 440 g (+/- 10g)
• Crown diameter: 56 mm
• Rake : 45 mm
• Carbon pads with aluminium insert for 12 mm axle thru axis
• For wheels of 700c
• Planned for flat mount and 160 mm disc
• Can accommodate tires up to 28 mm wide
